Anchor Audio Beacon Deluxe Package

Description


Beacon combines the clarity and smooth sound coverage of a line array system with a patent-pending enclosure that eliminates the need for a speaker stand. The enclosure includes three 8" woofers and an array of eight 4.5" mid-range speakers that deploys up to a height of 6'. The Beacon provides a 120 degree pattern of a distance of 500' which covers the area of a football field with just one system. The Beacon is a one of a kind in portable sound systems.
  • Lightweight speaker array - eight 4.5" speakers
  • Durable case with wheels and retractable handle
  • Three 8" woofers
  • 300W AC / 60W DC
  • Proprietary Class D amplifier
  • True AC/DC, 110/220 power supply
  • Two universal mic input jacks
  • Two built in UHF 16 channel wireless microphone receivers
  • Choice of (2) transmitters: WH-8000 Handheld or WB8000 body pack
  • Choice of any (2) wireless mics
  • Built-in CD/MP3 Combo player
  • Two nylon mesh storage bags
  • "Voice over" music feature
  • 110 dB @ 1 meter
  • 6 year warranty
  • Watch a demo video
  • Bluetooth now standard
    Bluetooth now standard. Click here for specs.
  • Shipping is included to the continental US. AK and HI call for shipping quote.
Available Accessories (not included)
  •  MIC-90 Handheld Mic with 20 ft. XLR Cable: $105
  • HC-1660 Beacon Hard Case with Pick 'N Pluck Foam: $399

Specifications

  • Rated Power Output  150 watts AC / 125 watts DC
  • Max SPL @ Rated Power  112 dB
  • Battery  Two 12 Volt rechargeable, 9.0 AH Full recharge: approx 7 hrs.
  • Frequency Response  60 Hz – 15 kHz ± 3dB
  • Line Output (post fader)  isolated, 600 ohm, 1/4” phone
  • AC Power Reqs.  100 – 240 VAC, 50/60 Hz, 300W max
  • DC Out  12V 500mA
  • USB  5V 500mA
  • Dimensions (HWD)  26.25 x 11 x 18”/66.7 x 28 x 45.7cm
  • Weight  51 pounds / 23 Kg
  • Mic Inputs:  Lo-Z (1 KW), balanced, XLR 12 VDC condenser mic (phantom) power Hi-Z (10 KW), unbalanced, 1/4” phone Hi-Z (10 KW), unbalanced, 1/8” stereo,1/4” phone
  • Line In/Out  unbalanced, stereo RCA
  • Sensitivity For Rated Output
  • Lo-Z Microphone  -52 dBV (2.5 mVrms)
  • Hi-Z Microphone  -43 dBV (7.5 mVrms)
  • Auxiliary (line)  -14 dBV (200 mVrms)
  • Phantom Power  36V
  • Bluetooth Option (standard starting Aug. 1)
Product form

Beacon combines the clarity and smooth sound coverage of a line array system with a patent-pending enclosure that eliminates the... Read more

SKU: ANCHOR-BEA-BPDUAL-0

$4,125.00 $3,300.00
